170mAh 20C LiPo Battery

A compact 170mAh rechargeable LiPo battery for small robots, portable electronics and DIY projects. Includes an integrated protection circuit and a pre-fitted two-pin connector.

• Capacity: 170mAh
• Nominal voltage: 3.7V (single-cell LiPo)
• Fully charged voltage: 4.2V
• Energy: 0.629Wh
• Maximum discharge rate: 15C (2.55A)
• Maximum charging current: 170mA
• Approximate dimensions: 22.5 × 17 × 8.5mm, excluding wires and connector
• Approximate weight: 4.5g
• Connector: MOLEX 51021-2P
• Protection: Overcharge, over-discharge, overcurrent and short circuit

• Check connector polarity before connecting. Use a compatible single-cell LiPo charger with a 4.2V charge limit and charging current no higher than 170mA. Do not connect directly to USB.
• Charge between 0°C and 45°C on a non-flammable surface, away from combustible materials. Do not charge unattended.
• Do not short-circuit, puncture, crush, bend or dismantle. Keep away from heat, fire, water and young children.
• Stop using or charging if the battery is swollen, damaged, leaking or unusually hot.
• Store disconnected, approximately half charged, in a cool, dry place. Take used batteries to a battery collection point; do not dispose of them in household waste. Insulate the terminals before disposal.

This battery ships directly from China to supported destinations and may arrive separately from other Microbots products. Shipping costs and estimated delivery times are provided at checkout or in your shipping quote.

DDP (Delivered Duty Paid) shipping options are available for supported destinations, with applicable import duties and taxes included in the quoted total. For non-DDP shipments, additional import taxes, duties or clearance fees may be payable on arrival.

Product SKU: MB-MM-BA-01
Battery Model: GEB851720
Country of Manufacture: China
Manufacturer: General Electronics Technology Co., Ltd.
